3COM
®
SWITCH 7700 FAMILY DATA SHEET
Specifications
All information in this section is relevant to all members
of the 3Com Switch 7700 family, unless stated other-
wise.
Capacities and Performance
Switch 7700 4-slot:
One switch fabric, three optional payload slots
Backplane: 48 Gbps, max
Bandwidth: 120 Gbps, max
Throughput: 88 Mpps, max
Switch 7700 7-slot:
One s
witch fabric, six optional payload slots
Backplane: 96 Gbps, max
Bandwidth: 240 Gbps, max
Throughput: 177 Mpps, max
Switch 7700R 8-slot:
One switch fabric, one optional redundant fabric, six
optional pa
yload slots
Backplane: 96 Gbps, max
Bandwidth: 240 Gbps, max
Throughput: 177 Mpps, max
All models:
Layer 3: 64 interfaces, IP routing at 48 Mpps, 64k IP
routing entries
Connectivity:
Mix and match in available payload slots:
48-port 10BASE-T/100BASE-TX
8-port 10/100/1000BASE-T
20-port 10/100/1000BASE-T
8-port 1000BASE-X (GBIC)
20-port 1000BASE-X (SFP)
24-port 100BASE-FX (multi-mode fiber)
1-port 10GBASE-X (Xenpak)
4-port 1000BASE-T
†
4-port 1000BASE-X (SFP)
†
Dimensions
Switch 7700 4-slot:
Height: 35.2 cm (13.8 in)
Width: 43.6 cm (17.2 in)
Depth: 48.0 cm (18.9 in)
Weight (fully loaded chassis): <46 kg (102 lbs)
Switch 7700 7-slot:
Height: 48.6 cm (19.1 in)
Width: 43.6 cm (17.2 in)
Depth: 48.0 cm (18.9 in)
Weight (fully loaded chassis): <70 kg (154 lbs)
Switch 7700R 8-slot:
Height: 51.9 cm (20.4 in)
Width: 43.6 cm (17.2 in)
Depth: 48.0 cm (18.9 in)
W
eight (full
y loaded chassis): <70 kg (154 lbs)
Power Supply
550 W AC Power Supply
Input v
olta
g
e: 100-240 VAC autoranging
Operating frequency: 47-63 Hz
Maximum current: 15A at 110 VAC; 7A at 200 VAC
Maximum output power: 460 W
Environmental Requirements
Operating temperature:
0° to 40°C (32° to 104°F)
Operating humidity:
5% to 85% non-condensing
Storage temperature:
-40° to 70°C (-40° to 158°F)
Storage humidity:
10% to 90% non-condensing
MTBF
Switch 7700 Gigabit Ethernet Switch Fabric (3C16857):
63 years (552,000 hours)
Switch 7700 1000BASE-X Module (8-port 3C16858):
66 years (583,000 hours)
Switch 7700 10/100/1000BASE-T Module (8-port 3C16859):
66 years (583,000 hours)
Switch 7700 10/100BASE-TX Module (3C16860):
38 years (336,000 hours)
Switch 7700 100BASE-FX Module (3C16861):
63 years (552,000 hours)
Switch 7700 1000BASE-X Module (20-port, 3C16862):
63 years (552,000 hours)
Switch 7700 10/100/1000BASE-T Module (20-port, 3C16863):
38 years (336,000 hours)
Switch 7700 10GBASE-X Module (3C16875):
261 years (2,286,000 hours)
Security
IEEE 802.1X RADIUS
Access Contr
ol Lists (ACL)
Packet filtering
SNMP v3 encryption*
SSH 1.5 web session encryption*
Industry Standar
ds Supported
Ethernet Protocols
IEEE 802.1D (STP)
IEEE 802.1p (CoS)
IEEE 802.1Q (VLANs)
IEEE 802.1S (MSTP)
IEEE 802.1v (VLANs)
IEEE 802.1w (RSTP)
IEEE 802.1X (Security)
IEEE 802.3ad (LACP)
IEEE 802.3ae (10G Ethernet)
IEEE 802.3i (10BASE-T)
IEEE 802.3u (Fast Ethernet)
IEEE 802.3x (Flow Control)
IEEE 802.3z (Gigabit Ethernet)
Administration Protocols
RFC 768 (UDP)
RFC 783 (TFTP)
RFC 791 (IP)
RFC 792 (ICMP)
RFC 793 (TCP)
RFC 826 (ARP)
RFC 951, 1542 (BOOTP)
RFC 959 (FTP)
RFC 1058 (RIP v1)
RFC 1112 (IGMP v1)
RFC 1518, 1519 (CIDR)
RFC 1587 (OSPF NSSA option)
RFC 1723 (RIP v2)
RFC 1765 (OSPF Database Overflow)
RFC 1812 (IP v4)
RFC 2131 (DHCP)
RFC 2132 (DHCP and BOOTP Extension)
RFC 2138 (Radius Authentication)
RFC 2139 (Radius Accounting)
RFC 2236 (IGMP v2)
RFC 2267 (Network Ingress Filtering)
RFC 2328 (OSPF v2)
RFC 2338 (VRRP)
RFC 2362 (PIM-SM)
RFC 2370 (OSPF Opaque LSA Option)
RFC 2474 (Diffserv)
RFC 2622 (Routing policy)
RFC 2819 (RMON)
Management, inc
luding MIBs Supported
RFC 1155 (Structur
e and Mgmt Inf
ormation (SMI v1))
RFC 1157 (SNMP v1/v2c)
RFC 1213 (MIB II)
RFC 1213, 1573 (MIB II)
RFC 1493 (Brid
g
e MIB)
RFC 1573 (Priv
ate IF MIB)
RFC 1724 (RIP Version 2 MIB Extension)
RFC 1850 (OSPF Version 2 MIB Extension)
RFC 1901-1907 (SNMP v2c, SMI v2 and Revised MIB-II)
RFC 2233 (Interfaces MIB)
RFC 2271 (F
rameWork)
RFC 2571-2575 (SNMP v3)*
RFC 2578-2580 (SMI v2)
RFC 2618 (RADIUS Authentication Client MIB)
RFC 2620 (R
ADIUS Accounting Client MIB)
RFC 2665 (Pause control)
RFC 2668 (IEEE 802.3 MAU MIB)
RFC 2674 (VLAN MIB Extension)
RFC 2787 (VRRP MIB)
Emissions / Agency Approvals
CISPR 22 Class A
FCC Part 15 Class A
EN 55022 Class A
ICES-003 Class A
VCCI Class A
Korean Class A
CNS 13438 Class A
AS/NZS 3548 Class A
EN 61000-3-2
EN 61000-3-3
Immunity
Product conforms to:
EN 55024: 1998
EN 61000-4-2
EN 61000-4-3
EN 61000-4-4
EN 61000-4-5
EN 61000-4-6
EN 61000-4-11
Safety Agency Certifications
UL 60950 3rd ed.
IEC 60950: 1999, corr. Feb. 2000; all national deviations
EN 60950: 2000, ZB and ZC deviations
CSA 22.2 No. 950 3rd ed., 1995
NOM-019 SCFI, Mexico; AS/NZS 60950:2000,
Australia; Russian GOST safety approval
Management
SNMP and Telnet support
Multiple agents with single management entry point
RMON-1, SMON
RMON Gr
oups: Statistics, History, Alarms and Events
Statistics gathering and reporting
Command line interface
Connectivity: 10B
ASE-T (RJ-45) Ethernet, RS-232
control port
Management through 3Com management applications
- 3Com Netw
ork Supervisor
- 3Com Network Director
- 3Com Netw
or
k Administrator
- 3Com Enterprise Management Suite
Features of Advanced Feature Software
SNMP v3 and SSH
v1.5 Encryption (security)
BGP4 (WAN routing protocol)
IS-IS
(Large-scale WAN routing protocol)
W
arranty
Limited Hardware Warranty for one year. Limited
Software Warranty for ninety (90) days. See
www
.3com.com/w
arranty f
or details
.
†
For use only in Switch 7700 4-Slot Switch Fa
bric
*
Available in the 3Com Advanced Feature Software, at additional cost
